KEY-IOT (StarElink) SG500 Energy Consumption Industrial IoT Gateway

SG500 embedded energy monitoring gateway with 4G full network, dual LAN ports and multi serial interfaces. Optimized for water/electricity/gas metering collection, supports Modbus/HJ212, Linux secondary development and StarCloud batch management.

Specifications

Temp-30℃~+70℃
BrandKEY-IOT (StarElink)
ModelSG500 Energy Consumption Industrial IoT Gateway
Memory256MB RAM, 8GB Flash
SerialMulti RS485 meter interfaces
SystemLinux secondary development
FeatureEnergy data split statistics, cloud batch management
VoltageDC 12~36V
Cellular4G full network module
Ethernet2×10/100M LAN
MountingDIN Rail
ProtocolModbus RTU, HJ212, MQTT
ApplicationBuilding energy management, factory power monitoring
VPN FunctionIPSEC
Cellular Network4G LTE
Serial InterfaceRS485
