KEY-IOT (StarElink) SG600 4G Smart Pole Gateway

SG600 intelligent street light gateway with 4G module, gigabit LAN, dual-band Wi-Fi, serial and DC power output. Supports street light dimming, video access, environmental sensing, SNMP and StarCloud unified management for city smart poles.

Specifications

Temp-35℃~+75℃
BrandKEY-IOT (StarElink)
ModelSG600 4G Smart Pole Gateway
Wi-Fi2.4G+5.8G dual band optional
Memory512MB RAM,4GB EMMC Flash
SerialRS485 light control port
FeatureFOTA remote upgrade, traffic alarm, QoS speed limit
VoltageDC 9~36V
Cellular4G CAT4 full network
EthernetMulti 10/100/1000M LAN
MountingWall Mount
ProtocolModbus, MQTT, SNMP v1/v2/v3
ApplicationCity smart street light pole, video surveillance, environmental sensor
Power Output12V DC external power supply
VPN FunctionL2TP
Cellular Network4G LTE
Serial InterfaceRS485
