Routers & Gateways

KEY-IOT (StarElink) SG610 Multi-Function Smart Pole Gateway

SG610 upgraded multi-function smart pole gateway, expandable optical port/POE power supply, 4G+Wi-Fi dual communication, richer serial and IO control ports. Supports emergency alarm, public broadcasting access and multi-service convergence on smart poles.

Specifications

Temp-35℃~+75℃
BrandKEY-IOT (StarElink)
ModelSG610 Multi-Function Smart Pole Gateway
Wi-Fi2.4G/5.8G dual band Wi-Fi6 optional
Memory512MB RAM,4GB EMMC Flash
SerialMulti RS485 control ports
FeatureEmergency alarm access, multi-media convergence, cloud batch management
VoltageDC 9~36V wide power
Cellular4G full network module
EthernetGigabit LAN, POE power supply optional
MountingWall Mount
ApplicationNew city integrated smart light pole
VPN FunctionL2TP
Cellular Network5G
Serial InterfaceRS485

Documents
