Ethernet Switches
KEY-IOT (StarElink) SW05F 5-Port 100M Industrial Ethernet Switch
SW05F unmanaged 5-port 100Mbps industrial switch with 5 RJ45 auto-MDI/MDIX ports, storage-forward switching architecture, metal DIN rail housing, wide voltage dual redundant power. Plug-and-play design for factory PLC, sensor and small industrial networking.
Specifications
| MTBF | ≥300000h |
| Brand | KEY-IOT (StarElink) |
| Model | SW05F 5-Port 100M Industrial Ethernet Switch |
| Mount | DIN Rail / Wall-mounted |
| Ports | 5×10/100M auto MDI/MDIX RJ45 |
| Power | DC12~52V dual redundant,terminal input |
| Speed | 100M |
| Buffer | 1Mbit |
| Housing | Metal Alloy |
| Latency | <10μs |
| Protocol | IEEE802.3/3u/3x |
| MAC Table | 2K |
| PortCount | 5 |
| Application | Factory automation,PLC monitoring,small industrial IoT |
| PoE Support | Non-PoE |
| Storage Temp | -40℃ ~ +85℃ |
| Certification | FCC,CE,RoHS |
| Operating Temp | -40℃ ~ +75℃ |
| ProtectionGrade | IP40 |
| Protection Grade | IP40 |
| Switch Bandwidth | 1.6Gbps |
| Power Consumption | <3W |
